EcoFlow Alternator Charger Plus 1000
EcoFlow Alternator Charger Plus 1000
SKU:WS305-24861
Couldn't load pickup availability
EcoFlow Alternator Charger Plus 1000 Battery Charger: Maximum Charging Power on the Go – 1000 W, Wi‑Fi & Bluetooth, plus Solar Input
The EcoFlow Alternator Charger Plus 1000 is the high-power variant for anyone who wants to recharge as quickly as possible on the go. The system connects to the alternator of your 12V or 24V vehicle and delivers up to 1000 W. In addition, there is a solar input of up to 300 W. Wi-Fi and Bluetooth are supported for convenient operation and monitoring.
More than just an Alternator: Smartly combine Alternator + Solar
With the additional solar input (up to 300 W), the Alternator Charger Plus 1000 is particularly suitable for recreational vehicles and off-grid setups where you want to use solar during the day and additionally charge via the alternator while driving.
Three Operating Modes for a Stable On-Board Power System
- Charge Mode: ALT IN input 12 V/24 V DC (11–31 V DC), 75 A max; BATTERY output 24 V DC or 40–60 V DC, 20 A max, 1,000 W max
- Battery Maintenance Mode: BATTERY input 40–60 V DC, 3 A max; ALT IN output 13.8 V / 27.6 V DC, 100 W max
- Reverse Charge Mode: BATTERY input 40–60 V DC, 20 A max; ALT IN output 13.8 V / 27.6 V DC, 75 A max
Smart Connection: Wi‑Fi & Bluetooth
With Wi‑Fi and Bluetooth, the Alternator Charger Plus 1000 is designed for modern vehicle energy systems. This facilitates integration into your daily life and gives you a much better overview than simple charging solutions.
Protection & Design for Vehicle Use
The Alternator Charger Plus 1000 offers reverse polarity protection, overcurrent protection, short circuit protection, over- and undervoltage protection, and protection against deep discharge of the starter/vehicle battery. The fuse is rated at 125 A. With IP4X, the device is suitable for protected mounting. Operating temperature: –10 °C to 45 °C, humidity: up to 95%.
Dimensions & Weight
Dimensions: 276 × 187 × 38 mm, Weight: approx. 1.7 kg.
Your Advantages at a Glance
- Up to 1000 W charging power at the BATTERY Port
- ALT IN for 12 V/24 V: 11–31 V DC, 75 A max
- Flexible output: 24 V DC or 40–60 V DC, 20 A max
- Solar input up to 300 W: 11–60 V DC, 15 A max
- Wi‑Fi & Bluetooth supported
- Battery Maintenance Mode (up to 100 W) + Reverse Charge Mode (up to 75 A)
- Fuse 125 A, IP4X, extensive protection functions
- Compact: 276 × 187 × 38 mm, approx. 1.7 kg
Important Note on Cables
- Solar cable: not included – please order separately
- XT150 connector (to power station): included
If you're looking for maximum charging power while driving plus the option for additional solar input, the EcoFlow Alternator Charger Plus 1000 is the logical solution. It combines high performance, flexible operating modes, and smart connectivity – ideal for anyone who wants reliable and fast charging on the go.
| Technical Data | EcoFlow 1000 W Alternator Charger Plus |
| Charge Mode Input | 11 V - 31 V / max. 75 A |
| Charge Mode Output | 40 V - 60 V / max. 1000 W |
| Battery Maintenance Mode Input | 40 V - 60 V / max. 3 A |
| Battery Maintenance Mode Output | 13.8 V - 27.6 V / max. 100 W |
| Reverse Charge Mode Input | 40 V - 60 V / max. 20 A |
| Reverse Charge Mode Output | 13.8 V - 27.6 V / max. 75 A |
| WLAN | 2412 MHz - 2472 MHz |
| Bluetooth | 2402 MHz - 2480 MHz |
| Fuse Rated Current | 125 A |
| Operating Temperature | - 10 °C to + 45 °C |
| Weight | 1.7 kg |
| Dimensions | 276 x 187 x 38 mm |
