EcoFlow Power Kit Distribution Board

Smart Power Distribution with a System – EcoFlow Power Kit Distribution Panel

Optimal Energy Management for Self-Sufficient Power Systems

The EcoFlow AC/DC Smart Distribution Panel is the central interface for structured, safe, and flexible power distribution in your self-sufficient energy system – whether in a camper, tiny house, or for stationary off-grid solutions. The combination of easy installation, sophisticated technology, and smart control makes it the ideal solution for demanding energy projects.

Flexible Installation for Maximum Adaptability

You can choose between two mounting methods: inline or directly on the wall. Thanks to clearly labeled connections and tool-friendly wiring, installation is straightforward. LED indicators provide you with visual feedback on the system status at all times and facilitate monitoring.

Powerful Connections for AC and DC Circuits

• AC Input: 220–240 V, 50 Hz, max. 30 A
• DC Input: 10–30 V DC, max. 70 A
• AC Outputs: 6 connections, each up to 10 A
• DC Outputs: 12 fused connections – 6 of which are controllable via the Power Kit Console and app

Robust, Compact, and Designed for Mobile Use

With an IP21 protection rating and a wide operating temperature range of -25 °C to 60 °C, the panel is perfectly suited for demanding environments. The compact design saves space and allows for flexible integration into various installation environments.

Scope of Delivery:

• 1× AC/DC Smart Distribution Panel
• 2× Wall Mounting Brackets

Technical Data:

• Dimensions: 354 × 210 × 98 mm (H × W × D)
• Weight: 2.6 kg
• Protection Class: IP21

With the EcoFlow Distribution Panel, you have full control over your energy flows – reliable, efficient, and future-proof.
