Home › 4x4 Accessories › OSRAM LED BAR Headlight VX1000-CB DR SM, 12/24V, Singlemount








Lighting
OSRAM LED BAR Headlight VX1000-CB DR SM, 12/24V, Singlemount
Item no.: TR36-3LEDDL121-CB
€306,95
🇩🇪 Ships from Germany
↺ 14-day returns
💬 Advice
Flawless visibility on dark forest paths and country roads ensures greater safety on the road and off-road. A range of 385 meters is made possible by 84 high-performance LEDs. During limited light conditions and at dusk, the powerful 6000 Kelvin provide a daylight-like light perception.
The combination of high-quality workmanship and extremely light, yet robust materials ensures a long service life.
The headlight was tested in a DIN-certified environmental simulation laboratory for extreme external influences, such as dust, water, shocks, heat, cold, and continuous vibration. Accordingly, the IP protection class IP6K8, IP6K9K was confirmed.
OSRAM LED work and auxiliary lights offer the most sophisticated LED technology on the market. Please note: High beam and fog lights must be installed in pairs (except "Singlemount").
The manufacturer OSRAM grants a 5-year warranty on LED work and auxiliary lights.
The warranty conditions, scope of application, and the manufacturer's address(es) can be found at:
www.osram.de
Your statutory warranty remains unaffected.
Attention! Please note:
Every certified headlight has a reference number (abbreviated in our texts as REF. NO.). This is located directly on the lens cover or housing. The sum of all reference numbers of the headlights mounted on the vehicle (original + auxiliary headlights) must not exceed 100.
The combination of high-quality workmanship and extremely light, yet robust materials ensures a long service life.
The headlight was tested in a DIN-certified environmental simulation laboratory for extreme external influences, such as dust, water, shocks, heat, cold, and continuous vibration. Accordingly, the IP protection class IP6K8, IP6K9K was confirmed.
OSRAM LED work and auxiliary lights offer the most sophisticated LED technology on the market. Please note: High beam and fog lights must be installed in pairs (except "Singlemount").
The manufacturer OSRAM grants a 5-year warranty on LED work and auxiliary lights.
The warranty conditions, scope of application, and the manufacturer's address(es) can be found at:
www.osram.de
Your statutory warranty remains unaffected.
Attention! Please note:
Every certified headlight has a reference number (abbreviated in our texts as REF. NO.). This is located directly on the lens cover or housing. The sum of all reference numbers of the headlights mounted on the vehicle (original + auxiliary headlights) must not exceed 100.
Specifications
- Artikelnummer: LEDDL121-CB DR SM
- Ausführung: CB/SM = Combo/single mount
- Maße: 996x74x62
- Gewicht: 3300,00 g
- Nennspannung: 12/24 V
- Nennleistung: 108,00 W
- Prüfspannung: 13,5 V
- Lichtstrom: 10100 lm
- Farbtemperatur: 6000 K
- Light distance at 1lx [PIM]: 525 m
- Lebensdauer: 5000 h
- Anschluss zur Lampe: Kabelverbindung
- Technologie: LED
- Normen: ECE R10, R149
- Prüfzeichen-Zulassung: E57
- Schutzart: IP6K8, IP6K9K
- Referenznummer: K17.5 + 17.5
Product safety (GPSR)
Safety notices
Sicherheitshinweise gemäß GPSR
Lesen Sie vor der Benutzung sorgfältig die Bedienungs- bzw. Anbauanleitung.
Vorsicht: Elektrische Spannung.
Achtung: Heiße Oberfläche - Verbrennungsgefahr.
Achtung nicht im Rauschzustand verwenden.
Vorsicht vor scharfen und spitzen Gegenständen - Verletzungsgefahr.
Kein Spielzeug - nur sachgerecht verwenden!
Achten Sie auf eine sichere Umgebung.
Manufacturer contact
Hersteller & EU Verantwortlicher:
Osram GmbH
Marcel-Breuer-Straße 4
D 80807 München
Mail: contact@osram.com
