Victron Phoenix VE.Bus 24/3000 Inverter 2400 W

Victron Inverter 2400 W Continuous Power for 24 V Systems

SinusMax – Leading Technology
The Phoenix inverter range was developed for commercial use; it is suitable for a variety of applications. The development uncompromisingly aimed for an inverter with a clean sine wave output at high efficiency. By applying the latest hybrid HF technology, it was possible to present a quality product with compact dimensions and low weight, which can easily deliver any desired power.Highest Start-up Power
A key feature of SinusMax technology is its particularly high start-up power. This is not possible with conventional HF technology. Phoenix inverters are capable of handling the high inrush currents of, for example, refrigeration compressors, power tools and similar devices.

Virtually Unlimited Power through Parallel Operation and Three-Phase Operation
Up to six inverter units can be connected in parallel to increase power. For example, six 24/5000 units can deliver 24kW / 30kVA of power. Three-phase operation is also possible. Load transfer to other AC sources: The automatic load transfer switch For smaller loads, we recommend the Filax automatic transfer switch. Computers and other sensitive electronic devices can continue to operate virtually uninterrupted, as the switching times are very short (under 20 msec).

Computer Interfaces
All models have an RS-485 port. You only need our MK2 interface (see also under Accessories). This interface provides galvanic isolation between the inverter and the computer and converts from RS-485 to RS-232. An RS-232 to USB conversion cable is also available. With our VEConfigure software, which can be downloaded for free from our website www.victronenergy.com, the inverters can be adjusted as required. This includes output voltage and frequency, upper and lower voltage limits, and programming of the relay. The relay can be used, for example, to generate signals in special situations or to start a generator.

The inverters can also be used with VENet, Victron Energy's innovative power monitoring network, or other computer-controlled regulation and monitoring systems.

Technical Data

Item number	300-3021
Manufacturer part number	PIN243020000
Product type	12V DC to 230V AC voltage converter. The voltage converter has a pure sine wave and should be connected directly to the battery/accumulator.
Manufacturer	Victron Energy
AC continuous power (W)	2200W
Input voltage range (V DC)	19 - 33V
Output voltage (V)	230V AC / Alternating current
No-load self-consumption	20W
AC output frequency range (Hz)	50Hz / +-0.1Hz or 50Hz / +-0.1Hz (adjustable)
Power quality	true sine wave
No-load self-consumption in power-saving mode	10W
Operating ambient temperature range	-40°C to 65°C
IP protection class	IP21
AC peak power (W)	6000W
Permissible humidity	max. 95 % RH
Voltage regulation	24V DC / 230V AC
Dimensions (LxWxH)	36.2 x 25.8 x 21.8 cm
Weight	18.00 kg
