Victron Skylla TG Battery Charger 24/100 (1+1) 3-Phase 400 V

Victron Skylla-TG 24/100(1+1) 3-Phase 400 V – Professional 24 V Battery Charger for the Highest Demands

The Victron Skylla-TG 24/100(1+1) 3-Phase 400 V is a powerful, industrial-grade 24 V battery charger with 100 A charging current and two charging outputs. It was developed for demanding use in marine, industrial, commercial vehicle, and fleet applications and guarantees maximum efficiency, reliability, and longevity.

With its three-phase 400 V input, the charger is ideal for power-intensive systems that require a stable power supply – from yachts and service vehicles to emergency power and industrial systems.

Powerful Charging System with Dual Output

The main output delivers up to 100 A charging current for large house batteries, while the second output (1+1) automatically provides a starter battery with maintenance voltage. This keeps both battery systems optimally charged – without separate chargers or switching mechanisms.

The Skylla-TG is suitable for all common battery types such as AGM, Gel, wet batteries, or LiFePO₄ and automatically adjusts the charging process via intelligent electronics.

Adaptive 7-Stage Charging Algorithm

Thanks to the temperature-compensated, 7-stage charging process, the device ensures fast, safe, and gentle charging. The adaptive control dynamically adjusts charging time and voltage to the battery's condition – for maximum lifespan and full performance.

With optional sensors, voltage, current, and temperature can be precisely monitored and evaluated via external systems.

Robust & Reliable for Continuous Operation

The Skylla-TG 24/100 is designed for continuous operation under demanding environmental conditions. The high-quality aluminum housing, active cooling, and efficient power regulation ensure stable function even at high ambient temperatures.

• Boats & Yachts
• Industrial Plants & Workshops
• Motorhomes & Commercial Vehicles
• Solar & Emergency Power Systems
• Service & Emergency Vehicles

Technical Data at a Glance

• Battery Voltage: 24 V
• Charging Current: 100 A
• Input Voltage: 3-Phase 400 V AC
• Charging Outputs: 2 (1 main output + 1 starter battery output)
• Charging Process: 7-stage, adaptive & temperature-compensated
• Compatible Battery Types: AGM, Gel, Wet, LiFePO₄
• Protection Functions: Overload, overtemperature, short-circuit & reverse polarity protection
• Active Cooling for Continuous Operation
• Industrial-grade Aluminum Housing

Your Advantages at a Glance

• 100 A Charging Current – high charging power for large battery systems
• Three-phase 400 V Input for stable supply
• Dual Output (1+1) for main & starter battery
• Adaptive 7-stage charging algorithm for optimal efficiency
• Temperature compensation for precise charging
• Compatible with AGM, Gel, Wet & LiFePO₄
• Robust, durable & low-maintenance
• Ideal for marine, industrial & fleet applications

Designed for Demanding Energy Environments

The Victron Skylla-TG 24/100(1+1) 3-Phase 400 V stands for uncompromising quality and highest charging efficiency. Whether on board a yacht, in a workshop, or in an emergency power system – this charger ensures constant performance, safe battery care, and maximum operational readiness.

Documents & Downloads

• Datasheet Skylla TG 24/100 400V
• Manual Skylla TG 24/100 400V
