Votronic Waste Water Tank Gauge S - 5313

Votronic Waste Water Tank Display S

The optimized monitoring solution

VOTRONIC tank gauges are designed for accurate fill level measurement and can be used for all tank materials and tank sizes. They differ in the arrangement of the three-color display LEDs at the ends of the range and in the symbol imprint on the front panel. The fill levels of the tanks are clearly displayed as light bars with 10 three-color LEDs each, allowing for precise determination of the tank fill levels at a glance. The displays work continuously, as intermediate levels are shown with variable brightness, making trends immediately recognizable.

When filling and emptying the tanks, the continuously rising or falling display provides the user with a direct representation of the current fill level, thus allowing complete control of the process. The continuous operation of the display also contributes to this. The display can be switched on and off at the touch of a button or switches off automatically after approx. 10 minutes.

The display units are designed as a panel version to match the VOTRONIC module system and integrate perfectly with other VOTRONIC display units (uniform height 85 mm). Of course, it is also possible to retrofit a single display in the vehicle. Small front panel dimensions and the particularly low installation depth of only 18 mm allow installation almost anywhere. The storage space behind it can thus continue to be used.

The devices are protected against reverse polarity and overload and are easily connected via screw terminals on the back of the device. Installation and operating instructions as well as a drilling template for the furniture cutout are included in the scope of delivery. The displays, like the sensors, are suitable for 12V and 24V operation.

Votronic Waste Water Tank Display S

Documents & Downloads

• Operating instructions
