The Votronic Solar Controller MPP 260 CI (Art. No. 1718) is the updated version of the proven MPPT charge controller – now with a new charging curve for heated LiFePO4 batteries, which also works without a temperature sensor. Visibly recognizable by the black connection terminals (instead of green) and the additional "T" in the designation. As a link between solar panel(s) and battery(ies), it ensures effective and reliable battery charging – ideal for motorhomes, caravans, boats, and self-sufficient solar systems.

MPPT Technology for Maximum Power Output

With MPP technology (Maximum Power Point Tracking), the controller automatically determines the maximum power output of the solar modules several times per second. The voltage surplus of the solar module is converted into a higher charging current for the battery – realized by high-frequency switching regulator technology with high efficiency. The result: shorter charging times and the best possible power utilization of your solar system.

New in Version 1718

The most important innovation of version 1718 is the additional charging curve for heated LiFePO4 batteries. This also works without the use of a temperature sensor – a clear practical advantage. The new version is easily recognizable externally by the black connection terminals (instead of the previous green ones).

Features at a Glance

• MPPT charging (Maximum Power Point Tracking) – automatically determined several times per second.
• CI-Bus connection: Display of all relevant data on a central vehicle display.
• 8 switchable charging curves for lead, gel, AGM, and LiFePO4 batteries – including a new curve for heated lithium batteries (usable without temperature sensor).
• Two battery charging outputs: Automatic charging of the main supply battery (12 V) as well as trickle charging and charge retention (max. 1 A) of the vehicle starter battery with protection against overcharging.
• Measurement output for EBL: Allows convenient use of a solar current display built into the electrical block.
• Switching output AES: In case of a continuous ample solar power surplus, this causes refrigerators with "AES" to automatically switch from gas to 12 V operation.
• Overcharge protection: Regulates the charging current back in case of too much solar power and a full battery – ensures immediate recharging when power is consumed.
• Parallel/Buffer operation: Compliance with charging regulations even when consumers are operating simultaneously.
• "IU1oU2" charging curve: Prevents harmful acid stratification (lead) and ensures equalization charging of individual battery cells, followed by automatic trickle charging.
• On-board power filter: Problem-free parallel operation with wind and engine generators, mains chargers, alternators, etc.
• Connection for battery temperature sensor: Absolutely necessary when the standard lithium curve is set.

Quality Made in Germany

Votronic MPP charge controllers are manufactured in Germany and are among the most powerful and reliable charge controllers on the market. The MPP 260 CI 1718 operates fully automatically, is maintenance-free, and offers you a well-thought-out overall package with up to 260 W solar power, two charging outputs, and the CI-Bus connection – for maximum independence on the go and at home.
