Votronic Standby Charger Pro 12V - 3063

Votronic StandBy Charger Pro 12V

Automatic top-up charge and battery maintenance

The VOTRONIC StandBy-Charger is used for automatic top-up charging and trickle charging of the starter battery or the auxiliary battery if the mains charger, solar charge controller or generator only has one charging output. The device can be easily retrofitted by simply connecting it between the house and starter battery or house and auxiliary battery, without having to change the existing wiring.

If, for example, the mains charger is in operation and charging the house battery, a small portion of the charging current will also charge the second battery (starter battery or auxiliary battery), depending on its state of charge. This trickle charging works automatically and is recognizable by an increased voltage level of the second battery. Overcharging of the second battery is ruled out, as the charging voltage is reduced by at least 0.6V and the charging current is limited to 3A (24V version: 2A).

Votronic StandBy Charger Pro 12V

Documents & Downloads

• Manual Standby Charger Pro 3063
